Stereoscopic triangle(3D) roll core winding machine



Stereoscopic triangle(3D) roll core winding machine
  • Product name:Stereoscopic triangle(3D) roll core winding machine
  • Scope of application:
  • Remark:
  • Product category:Transformer winding machine
  • Watch Product Videos
  • PDF Download



Product description


S
tereoscopic triangle(3D) roll core winding machine

1.we specializes in providing stereoscopic triangle roll core winding machine,stereoscopic triange foil winding machine offer technical support of S11,S12,S13 etc transformer stereo triangle core coil.

2.JTR core winding machine can wind  S11,S12,S13 etc transformer stereo triangle core coil.

3.Adpot Mitsubishi PLC ,Tai wan Delta incerter,Tai wan Hiwin linear guide.

4.Frenquency control of motor speed,smooth transmission.

5.High adn low voltage coil winding once completed.

6.Keep core in the middle,clamp and locate easier.

7.Counting encoder,good braking performance

8.Reasonable design,simple structure

Model

Stereoscpic triangle roll core winding machine

Transformer specifications

30-16000KVA

Three column center distance

Horizontal

Max outer diameter

820mm

Winding center distance is adjustable

250mm

Bear weight of worktable

2000kg

Spindle speed

0-250rpm

Control mode

Frequency converter speed control

Count range

Encoder counts 0.1tums

Total motor power

4.5KW

Winding power

3KW

Rotate core motor power

1.1KW

Workbench shift range

200mm

Weight

About 1200kg
